The 25Gbps SFP28 SR Transceiver is a high-performance optical module designed for short-range communication over multimode fiber (MMF) with a maximum link length of 70 meters using OM3 fiber and 100 meters using OM4 fiber. It features an 850nm VCSEL transmitter and a GaAs PIN photodiode receiver, providing reliable data transfer at a rate of 25.78Gbps. This module is ideal for applications such as inter-rack connections, high-speed servers, high-performance computing clusters, and SANs. It adheres to SFP28 MSA, SFF-8431, and SFF-8432 standards, ensuring compatibility with modern networking systems.
Operating on a +3.3V power supply, the transceiver consumes less than 1W, making it energy efficient. It supports a commercial temperature range of 0°C to +70°C, with an industrial option available for operation between -40°C and +85°C. The hot-pluggable design with a dual LC interface simplifies integration into existing systems, and its compliance with RoHS underscores an environmentally friendly design.
Optically, the transmitter provides a center wavelength between 840nm and 860nm, with an average optical power ranging from -5dBm to +2.4dBm. The extinction ratio is maintained at 3dB, ensuring reliable signal quality. The receiver operates within the same wavelength range and offers a sensitivity of -10.3dBm, with an overload threshold of +2.4dBm. Additional features, such as Loss of Signal (LOS) functionality, enhance diagnostics and network stability.
The transceiver supports advanced digital diagnostics as defined by SFF-8472, allowing real-time monitoring of parameters such as temperature, voltage, bias current, transmitted power, and received power. Alarms and warning flags provide alerts for deviations from optimal conditions, ensuring proactive maintenance and operational reliability. The two-wire serial interface provides access to these diagnostics, enabling efficient management of network infrastructure.
In summary, the 25Gbps SFP28 SR Transceiver is a reliable and energy-efficient solution for high-speed, short-distance networking. Its advanced features, compliance with industry standards, and robust design make it an essential component for data centers and enterprise networks.
At Carritech, we pride ourselves on our exceptional service and commitment to meeting our customers’ needs. Our extensive range of SFP transceivers is designed to cater to various requirements, ensuring that you receive the best solutions for your projects. We understand the importance of timely delivery, and our efficient processes are geared towards providing you with the products you need as quickly as possible. Our dedicated team works tirelessly to ensure that your orders are processed and dispatched promptly, so you can rely on us for swift and reliable service.
We recognise that every project is unique, and our flexible approach allows us to adapt to your specific needs. Whether you require immediate delivery or have more complex requirements, we are here to support you every step of the way. Our commitment to customer satisfaction means that we go above and beyond to ensure that you receive your SFP transceivers in a timely manner, without compromising on quality. Trust Carritech to deliver the solutions you need, when you need them.
At Carritech Optics, we stand by the quality and reliability of our optical transceivers. That’s why we proudly offer a lifetime warranty on all products as a testament to our commitment to excellence and customer satisfaction.
What Does Our Lifetime Warranty Cover?
Our lifetime warranty provides comprehensive coverage for the entire lifecycle of your optical transceivers, ensuring you experience complete peace of mind when choosing Carritech Optics. The warranty covers:
Easy Claims Process
Should you ever need to make a warranty claim, our team is here to assist you. Simply contact our support team with your product details, and we’ll guide you through a quick and hassle-free process to resolve the issue.
Your Network’s Performance, Guaranteed
Carritech Optics is dedicated to providing high-quality optical solutions that you can trust for the long haul. With our lifetime warranty, you can confidently invest in our products, knowing that we’re with you every step of the way.
